0639-0-15-15-34-14-10-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSTD. CONNECTOR JACK RECEPTACLE
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
- 1$0.77328
Quote It
Technical Details
- Series:0639
- Package:Bulk
- Part Status:Active
- Tail Type:No Tail
- Termination:Press-Fit
- Length - Overall:0.140" (3.56mm)
- Accepts Pin Diameter:0.032" ~ 0.046" (0.81mm ~ 1.17mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.064" (1.63mm)
- Mounting Hole Diameter:0.091" (2.31mm)
- Flange Diameter:0.089" (2.26mm)
- Tail Diameter:-
- Socket Depth:0.125" (3.18mm)
- Contact Material:Beryllium Copper
- Contact Finish:-
- Contact Finish Thickness:-
