0298-4-15-80-06-27-10-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 0298-4-15-80-06-27-10-0 Datasheet
-
ECAD Model
- Share
In Stock: 193
Can ship immediately
Pricing:
- 1$0.7941
- 1,000$0.7941
Quote It
Technical Details
- Series:0298
- Package:Bulk
- Part Status:Active
- Tail Type:Standard Tail
- Termination:Swage
- Length - Overall:0.450" (11.43mm)
- Accepts Pin Diameter:0.022" ~ 0.032" (0.56mm ~ 0.81mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.051" (1.30mm)
- Mounting Hole Diameter:0.060" (1.52mm)
- Flange Diameter:0.094" (2.39mm)
- Tail Diameter:0.026" (0.66mm)
- Socket Depth:0.150" (3.81mm)
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
