SC630JWR
Mallory Sonalert Products
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAUDIO PIEZO IND 9-30V PNL MNT
- CategoryAlarms, Buzzers, and Sirens
- Datasheet SC630JWR Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$31.2584
- 25$29.3784
Quote It
Technical Details
- Series:SC
- Package:Bulk
- Part Status:Active
- Driver Circuitry:Indicator, Internally Driven
- Input Type:DC
- Voltage - Rated:-
- Voltage Range:9 ~ 30V
- Frequency:2.3kHz
- Technology:Piezo
- Operating Mode:Warble
- Duration:0.5 ~ 2 PPS
- Sound Pressure Level (SPL):65dB @ 9V, 61cm
- Current - Supply:40mA
- Port Location:Top
- Operating Temperature:-30°C ~ 65°C
- Approval Agency:-
- Ratings:-
- Ingress Protection:-
- Mounting Type:Panel Mount
- Termination:Screw Terminal, Quick Connect Tab - 0.250" (6.35mm)
- Size / Dimension:1.692" Dia (42.98mm)
- Height - Seated (Max):1.399" (35.54mm)
