T1071NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionXFRMR 4PORT 1:1/1.26 1.2MH SMD
- CategoryPulse Transformers
- Datasheet T1071NLT Datasheet
-
ECAD Model
- Share
In Stock: 159
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Transformer Type:T1/E1 (Quad)
- Inductance:1.2mH, 1.2mH
- ET (Volt-Time):-
- Turns Ratio - Primary:Secondary:1:1/1.26 Transmitter, 1:2CT Receiver
- Mounting Type:Surface Mount
- Size / Dimension:1.125" L x 0.485" W (28.58mm x 12.32mm)
- Height - Seated (Max):0.230" (5.84mm)
- Operating Temperature:0°C ~ 70°C
