PLM-40-500

Technical Details

• Series:PLM-40 (40W)
• Package:Box
• Part Status:Obsolete
• Type:Constant Current
• Topology:AC DC Converter
• Number of Outputs:1
• Voltage - Input (Min):110VAC
• Voltage - Input (Max):295VAC
• Voltage - Output:40 ~ 80V
• Current - Output (Max):500mA
• Power (Watts):40 W

• Voltage - Isolation:3.75 kV
• Dimming:-
• Features:OTP, SCP
• Ratings:IP30
• Operating Temperature:-30°C ~ 40°C
• Efficiency:88%
• Termination Style:Terminal Block
• Size / Dimension:6.89" L x 1.65" W x 0.94" H (175.0mm x 42.0mm x 24.0mm)
• Approval Agency:CB, CCC, CE, cURus, ENEC
• Standard Number:-
