875075155005
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM POLY 390UF 20% 6.3V SMD
- CategoryAluminum - Polymer Capacitors
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
- 1$0.97
- 400$0.642
- 800$0.562
- 1,200$0.535
Quote It
Technical Details
- Series:WCAP-PSLC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Polymer
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):8mOhm
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:260 mA @ 120 Hz
- Ripple Current @ High Frequency:5.2 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.461" (11.70mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
