GYA1H680MCW1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- Description50V 68UF 20% CHIP TYPE, POLYMER
- CategoryAluminum - Polymer Capacitors
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
- 1$1.7
Quote It
Technical Details
- Series:GYA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Hybrid
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):30mOhm
- Lifetime @ Temp.:4000 Hrs @ 125°C
- Operating Temperature:-55°C ~ 125°C
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:187.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.25 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.433" (11.00mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
