HHXE350ARA151MHA0G
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM HYBRD 150UF 20% 35V SMD
- CategoryAluminum - Polymer Capacitors
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$2
Quote It
Technical Details
- Series:HXE
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Hybrid
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):22mOhm
- Lifetime @ Temp.:4000 Hrs @ 135°C
- Operating Temperature:-55°C ~ 135°C
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:290 mA @ 120 Hz
- Ripple Current @ High Frequency:2.9 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
