EEH-AZF1H101B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM POLY 100UF 20% 50V T/H
- CategoryAluminum - Polymer Capacitors
-
ECAD Model
- Share
In Stock: 172
Can ship immediately
Pricing:
- 1$2.14
Quote It
Technical Details
- Series:ZF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Hybrid
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):28mOhm
- Lifetime @ Temp.:1000 Hrs @ 150°C
- Operating Temperature:-55°C ~ 150°C
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:135 mA @ 100 Hz
- Ripple Current @ High Frequency:900 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
