RFS0E181MCN1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM POLY 180UF 20% 2.5V SMD
- CategoryAluminum - Polymer Capacitors
- Datasheet RFS0E181MCN1GS Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$0.24766
- 1,000$0.22514
Quote It
Technical Details
- Series:FPCAP, RFS
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Polymer
- Capacitance:180 µF
- Tolerance:±20%
- Voltage - Rated:2.5 V
- ESR (Equivalent Series Resistance):21mOhm
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:267 mA @ 120 Hz
- Ripple Current @ High Frequency:2.67 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.224" (5.70mm)
- Surface Mount Land Size:0.209" L x 0.209" W (5.30mm x 5.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
