ECASD40J686M015K00
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM POLY 68UF 20% 6.3V SMD
- CategoryAluminum - Polymer Capacitors
- Datasheet ECASD40J686M015K00 Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$0.33587
- 3,000$0.33587
Quote It
Technical Details
- Series:ECAS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Polymer
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):15mOhm
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:2 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.287" L x 0.169" W (7.30mm x 4.30mm)
- Height - Seated (Max):0.075" (1.90mm)
- Surface Mount Land Size:0.287" L x 0.169" W (7.30mm x 4.30mm)
- Mounting Type:Surface Mount
- Package / Case:2917 (7343 Metric)
