MAL218497001E3
Vishay BC Components/Beyshlag/Draloric
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 35V 2000H
- CategoryAluminum - Polymer Capacitors
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$0.4374
Quote It
Technical Details
- Series:184 CPNS
- Package:Box
- Part Status:Active
- Type:Polymer
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):50mOhm
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:65 mA @ 120 Hz
- Ripple Current @ High Frequency:1.3 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.240" (6.10mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
