875115150002

Technical Details

• Series:WCAP-PSHP
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Polymer
• Capacitance:270 µF
• Tolerance:±20%
• Voltage - Rated:6.3 V
• ESR (Equivalent Series Resistance):20mOhm
• Lifetime @ Temp.:2000 Hrs @ 105°C
• Operating Temperature:-55°C ~ 105°C
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:175 mA @ 120 Hz
• Ripple Current @ High Frequency:3.5 A @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.315" Dia (8.00mm)
• Height - Seated (Max):0.303" (7.70mm)
• Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
