RPS0G681MCN1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM POLY 680UF 20% 4V SMD
- CategoryAluminum - Polymer Capacitors
- Datasheet RPS0G681MCN1GS Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
- 1$0.57008
- 500$0.51825
Quote It
Technical Details
- Series:FPCAP, RPS
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Polymer
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:4 V
- ESR (Equivalent Series Resistance):22mOhm
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:380 mA @ 120 Hz
- Ripple Current @ High Frequency:3.8 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.315" (8.00mm)
- Surface Mount Land Size:0.406" L x 0.406" W (10.30mm x 10.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
