EEF-HX1C680R
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM POLY 68UF 20% 16V SMD
- CategoryAluminum - Polymer Capacitors
- Datasheet EEF-HX1C680R Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$0.63144
- 3,500$0.60273
Quote It
Technical Details
- Series:SP-Cap HX
- Package:Tape & Reel (TR)
- Part Status:Not For New Designs
- Type:Polymer
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):40mOhm
- Lifetime @ Temp.:1000 Hrs @ 125°C
- Operating Temperature:-55°C ~ 125°C
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:3.2 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.287" L x 0.169" W (7.30mm x 4.30mm)
- Height - Seated (Max):0.079" (2.00mm)
- Surface Mount Land Size:-
- Mounting Type:Surface Mount
- Package / Case:2917 (7343 Metric)
