EEF-CD0K150ER

Technical Details

• Series:SP-Cap CD
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:Polymer
• Capacitance:15 µF
• Tolerance:±20%
• Voltage - Rated:8 V
• ESR (Equivalent Series Resistance):40mOhm
• Lifetime @ Temp.:1000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:-
• Ripple Current @ High Frequency:1.6 A @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.287" L x 0.169" W (7.30mm x 4.30mm)
• Height - Seated (Max):0.075" (1.90mm)
• Surface Mount Land Size:-
• Mounting Type:Surface Mount
• Package / Case:2917 (7343 Metric)
