8SXB33M

Technical Details

• Series:PC-CON, SXB
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Polymer
• Capacitance:33 µF
• Tolerance:±20%
• Voltage - Rated:8 V
• ESR (Equivalent Series Resistance):18mOhm
• Lifetime @ Temp.:2000 Hrs @ 105°C
• Operating Temperature:-55°C ~ 105°C
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:-
• Ripple Current @ High Frequency:2.5 A @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.287" L x 0.169" W (7.30mm x 4.30mm)
• Height - Seated (Max):0.075" (1.90mm)
• Surface Mount Land Size:0.287" L x 0.169" W (7.30mm x 4.30mm)
• Mounting Type:Surface Mount
• Package / Case:2917 (7343 Metric)
