NCP81075MNTXG
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE DRV HI-SIDE/LO-SIDE 8DFN
- CategoryPMIC - Gate Drivers
- Datasheet NCP81075MNTXG Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$2.66
- 4,000$2.60595
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Driven Configuration:High-Side or Low-Side
- Channel Type:Independent
- Number of Drivers:2
- Gate Type:N-Channel MOSFET
- Voltage - Supply:8.5V ~ 20V
- Logic Voltage - VIL, VIH:0.8V, 2.7V
- Current - Peak Output (Source, Sink):4A, 4A
- Input Type:Non-Inverting
- High Side Voltage - Max (Bootstrap):200 V
- Rise / Fall Time (Typ):8ns, 7ns
- Operating Temperature:-40°C ~ 140°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:8-VDFN Exposed Pad
- Supplier Device Package:8-DFN (4x4)
