ADP3654ARHZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE DRVR LOW-SIDE 8MINISOIC
- CategoryPMIC - Gate Drivers
- Datasheet ADP3654ARHZ Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
- 1$2.06
- 50$1.74274
- 100$1.48476
- 500$1.21986
- 1,000$1.01073
- 2,500$0.94102
- 5,000$0.90617
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Driven Configuration:Low-Side
- Channel Type:Independent
- Number of Drivers:2
- Gate Type:N-Channel MOSFET
- Voltage - Supply:4.5V ~ 18V
- Logic Voltage - VIL, VIH:0.8V, 2V
- Current - Peak Output (Source, Sink):4A, 4A
- Input Type:Non-Inverting
- High Side Voltage - Max (Bootstrap):-
- Rise / Fall Time (Typ):10ns, 10ns
- Operating Temperature:-40°C ~ 125°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package:8-MiniSO-EP
