HIP2104FRAANZ
Intersil (Renesas Electronics America)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE DRVR HALF-BRIDGE 12DFN
- CategoryPMIC - Gate Drivers
- Datasheet HIP2104FRAANZ Datasheet
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$2.81
- 1,800$2.72076
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Driven Configuration:Half-Bridge
- Channel Type:Independent
- Number of Drivers:2
- Gate Type:N-Channel MOSFET
- Voltage - Supply:4.5V ~ 14V
- Logic Voltage - VIL, VIH:1.63V, 2.06V
- Current - Peak Output (Source, Sink):1A, 1A
- Input Type:Non-Inverting
- High Side Voltage - Max (Bootstrap):60 V
- Rise / Fall Time (Typ):8ns, 2ns
- Operating Temperature:-40°C ~ 125°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:12-VFDFN Exposed Pad
- Supplier Device Package:12-DFN (4x4)
