PA3747.205NL
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMMON MODE CHOKE 4A 2LN TH
- CategoryCommon Mode Chokes
- Datasheet PA3747.205NL Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$2.9232
- 950$2.9232
Quote It
Technical Details
- Series:PA3747
- Package:Tray
- Part Status:Active
- Filter Type:-
- Number of Lines:2
- Impedance @ Frequency:-
- Inductance @ Frequency:-
- Frequency Coupled to Inductance @ Frequency:-
- Current Rating (Max):4A
- DC Resistance (DCR) (Max):25.5mOhm
- Voltage Rating - DC:-
- Voltage Rating - AC:-
- Operating Temperature:-40°C ~ 125°C
- Ratings:-
- Approval Agency:-
- Features:-
- Mounting Type:Through Hole
- Size / Dimension:0.760" L x 0.717" W (19.30mm x 18.20mm)
- Height (Max):0.902" (22.90mm)
- Package / Case:Vertical, 4 PC Pin
