PV2-56R-XY
Panduit Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RING D-SHAPE 2AWG #5/16
- CategoryTerminals - Ring Connectors
- Datasheet PV2-56R-XY Datasheet
-
ECAD Model
- Share
In Stock: 1,283,767
Can ship immediately
Pricing:
- 1$4.47
- 10$4.34513
- 25$4.22405
- 50$4.10338
- 100$3.98281
- 500$3.86208
- 1,000$3.74139
Quote It
Technical Details
- Series:Pan-Term®
- Package:Bulk
- Part Status:Active
- Terminal Type:D-Shaped
- Stud/Tab Size:5/16 Stud
- Thickness:0.060" (1.52mm)
- Width - Outer Edges:0.680" (17.27mm)
- Length - Overall:1.960" (49.78mm)
- Mounting Type:Free Hanging (In-Line)
- Termination:Crimp
- Wire Gauge:2 AWG
- Insulation:Insulated
- Features:Brazed Seam
- Color:Red
- Contact Material:Copper
- Contact Finish:Tin
