1-696423-0
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RING CIRC 14-16AWG #1/2
- CategoryTerminals - Ring Connectors
- Datasheet 1-696423-0 Datasheet
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$0.99926
- 5,000$0.90594
Quote It
Technical Details
- Series:PIDG
- Package:Bulk
- Part Status:Active
- Terminal Type:Circular
- Stud/Tab Size:1/2 Stud
- Thickness:0.031" (0.79mm)
- Width - Outer Edges:0.713" (18.11mm)
- Length - Overall:1.298" (32.97mm)
- Mounting Type:Free Hanging (In-Line)
- Termination:Crimp
- Wire Gauge:14-16 AWG
- Insulation:Insulated
- Features:Radiation Resistant, Serrated Termination
- Color:Natural, Blue Stripe
- Contact Material:Copper
- Contact Finish:Tin
