54947-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RING D-SHAPE 8AWG #5/16
- CategoryTerminals - Ring Connectors
- Datasheet 54947-1 Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$1.1847
- 6,000$1.08956
Quote It
Technical Details
- Series:Plasti-Grip
- Package:Bulk
- Part Status:Active
- Terminal Type:D-Shaped
- Stud/Tab Size:5/16 Stud
- Thickness:0.040" (1.02mm)
- Width - Outer Edges:0.587" (14.91mm)
- Length - Overall:1.702" (43.23mm)
- Mounting Type:Free Hanging (In-Line)
- Termination:Crimp
- Wire Gauge:8 AWG
- Insulation:Insulated
- Features:-
- Color:Natural, Red Stripe
- Contact Material:Copper
- Contact Finish:Tin-Lead
