8-320567-2
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RING CIRC 10-12AWG #6 CRIMP
- CategoryTerminals - Ring Connectors
- Datasheet 8-320567-2 Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PIDG
- Package:Bulk
- Part Status:Active
- Terminal Type:Circular
- Stud/Tab Size:6 Stud
- Thickness:0.040" (1.02mm)
- Width - Outer Edges:0.375" (9.53mm)
- Length - Overall:1.083" (27.51mm)
- Mounting Type:Free Hanging (In-Line)
- Termination:Crimp
- Wire Gauge:10-12 AWG
- Insulation:Insulated
- Features:Serrated Termination
- Color:Yellow
- Contact Material:Copper
- Contact Finish:Tin
