MHMF022L1V2
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSERVOMOTOR 3000 RPM 200V
- CategoryMotors - AC, DC
- Datasheet MHMF022L1V2 Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$654.55
Quote It
Technical Details
- Series:MINAS A6
- Package:Box
- Part Status:Active
- Type:AC Motor
- Function:Servomotor
- Motor Type:-
- Voltage - Rated:200VAC
- RPM:3000 RPM
- Torque - Rated (oz-in / mNm):90.65 / 640
- Power - Rated:200W
- Encoder Type:Absolute
- Size / Dimension:Square - 2.362" x 2.362" (60.00mm x 60.00mm)
- Diameter - Shaft:0.433" (11.00mm)
- Length - Shaft and Bearing:1.181" (30.00mm)
- Mounting Hole Spacing:2.756" (70.00mm)
- Termination Style:Cable with Connector
- Features:Brake, Key, Oil Seal
- Gear Reduction Ratio:-
- Torque - Max Momentary (oz-in / mNm):315.8 / 2230
- Operating Temperature:0°C ~ 55°C
