ECMA-C11010RS
Delta Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSERVOMOTOR 3000 RPM 220V
- CategoryMotors - AC, DC
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$756
- 5$742.5
- 10$729
Quote It
Technical Details
- Series:ECMA
- Package:Box
- Part Status:Active
- Type:AC Motor
- Function:Servomotor
- Motor Type:-
- Voltage - Rated:220VAC
- RPM:3000 RPM
- Torque - Rated (oz-in / mNm):450.3 / 3180
- Power - Rated:1kW
- Encoder Type:Incremental
- Size / Dimension:Square - 3.937" x 3.937" (100.00mm x 100.00mm)
- Diameter - Shaft:0.866" (22.00mm)
- Length - Shaft and Bearing:1.772" (45.00mm)
- Mounting Hole Spacing:4.528" (115.00mm)
- Termination Style:Cable with Connector
- Features:Key, Oil Seal
- Gear Reduction Ratio:-
- Torque - Max Momentary (oz-in / mNm):1351 / 9540
- Operating Temperature:0°C ~ 40°C
