R88M-W40030T-G05BJ

Technical Details

• Series:OMNUC W
• Package:Bulk
• Part Status:Obsolete
• Type:AC Motor
• Function:Gearmotor
• Motor Type:-
• Voltage - Rated:200VAC
• RPM:3000 RPM
• Torque - Rated (oz-in / mNm):179.9 / 1270
• Power - Rated:400W

• Encoder Type:Absolute
• Size / Dimension:Square - 2.362" x 2.362" (60.00mm x 60.00mm)
• Diameter - Shaft:0.551" (14.00mm)
• Length - Shaft and Bearing:1.181" (30.00mm)
• Mounting Hole Spacing:2.756" (70.00mm)
• Termination Style:Wire Leads with Connector
• Features:-
• Gear Reduction Ratio:5
• Torque - Max Momentary (oz-in / mNm):541 / 3820
• Operating Temperature:0°C ~ 40°C
