MAMA082S1A

Technical Details

• Series:MINAS A4
• Package:Bulk
• Part Status:Obsolete
• Type:AC Motor
• Function:Servomotor
• Motor Type:-
• Voltage - Rated:200VAC
• RPM:5000 RPM
• Torque - Rated (oz-in / mNm):202.5 / 1430
• Power - Rated:750W

• Encoder Type:Absolute
• Size / Dimension:Square - 3.150" x 3.150" (80.00mm x 80.00mm)
• Diameter - Shaft:0.748" (19.00mm)
• Length - Shaft and Bearing:1.378" (35.00mm)
• Mounting Hole Spacing:3.543" (90.00mm)
• Termination Style:Cable with Connector
• Features:-
• Gear Reduction Ratio:-
• Torque - Max Momentary (oz-in / mNm):1014 / 7160
• Operating Temperature:0°C ~ 40°C
