SN74ACT534NSR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC FF D-TYPE SNGL 8BIT 20SO
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 2,162
Can ship immediately
Pricing:
- 1$1.2
- 2,000$0.364
Quote It
Technical Details
- Series:74ACT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Function:Standard
- Type:D-Type
- Output Type:Tri-State, Inverted
- Number of Elements:1
- Number of Bits per Element:8
- Clock Frequency:100 MHz
- Max Propagation Delay @ V, Max CL:11.5ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:24mA, 24mA
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Iq):4 µA
- Input Capacitance:4.5 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:20-SO
- Package / Case:20-SOIC (0.209", 5.30mm Width)
