SN74AHC174D
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC FF D-TYPE SNGL 6BIT 16SOIC
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 2,094
Can ship immediately
Pricing:
- 1$0.58
- 2,000$0.20432
Quote It
Technical Details
- Series:74AHC
- Package:Tube
- Part Status:Active
- Function:Master Reset
- Type:D-Type
- Output Type:Non-Inverted
- Number of Elements:1
- Number of Bits per Element:6
- Clock Frequency:180 MHz
- Max Propagation Delay @ V, Max CL:9.2ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:8mA, 8mA
- Voltage - Supply:2V ~ 5.5V
- Current - Quiescent (Iq):4 µA
- Input Capacitance:1.7 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:16-SOIC
- Package / Case:16-SOIC (0.154", 3.90mm Width)
