SN74ALS112ANSR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC FF JK TYPE DUAL 1BIT 16SO
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 2,200
Can ship immediately
Pricing:
- 1$1.48
- 2,000$0.5908
Quote It
Technical Details
- Series:74ALS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Function:Set(Preset) and Reset
- Type:JK Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:30 MHz
- Max Propagation Delay @ V, Max CL:19ns @ 5V, 50pF
- Trigger Type:Negative Edge
- Current - Output High, Low:400µA, 8mA
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Iq):4.5 mA
- Input Capacitance:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:16-SO
- Package / Case:16-SOIC (0.209", 5.30mm Width)
