74LV273N,112
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionD FLIP-FLOP
- CategoryLogic - Flip Flops
- Datasheet 74LV273N,112 Datasheet
-
ECAD Model
- Share
In Stock: 2,863
Can ship immediately
Pricing:
- 1$0.8
Quote It
Technical Details
- Series:74LV
- Package:Tube
- Part Status:Obsolete
- Function:Master Reset
- Type:D-Type
- Output Type:Non-Inverted
- Number of Elements:1
- Number of Bits per Element:8
- Clock Frequency:100 MHz
- Max Propagation Delay @ V, Max CL:16ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:12mA, 12mA
- Voltage - Supply:1V ~ 5.5V
- Current - Quiescent (Iq):160 µA
- Input Capacitance:3.5 pF
- Operating Temperature:-40°C ~ 125°C (TA)
- Mounting Type:Through Hole
- Supplier Device Package:20-DIP
- Package / Case:20-DIP (0.300", 7.62mm)
