74AC821SPC
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBUS DRIVER
- CategoryLogic - Flip Flops
- Datasheet 74AC821SPC Datasheet
-
ECAD Model
- Share
In Stock: 2,816
Can ship immediately
Pricing:
- 1$1
Quote It
Technical Details
- Series:74AC
- Package:Tube
- Part Status:Obsolete
- Function:Standard
- Type:D-Type
- Output Type:Tri-State, Non-Inverted
- Number of Elements:1
- Number of Bits per Element:10
- Clock Frequency:160 MHz
- Max Propagation Delay @ V, Max CL:9.5ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:24mA, 24mA
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Iq):80 µA
- Input Capacitance:4.5 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Supplier Device Package:24-PDIP
- Package / Case:24-DIP (0.300", 7.62mm)
