SN74LS107ADR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionJ-K FLIP-FLOP
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 2,429
Can ship immediately
Pricing:
- 1$1.14
Quote It
Technical Details
- Series:74LS
- Package:Bulk
- Part Status:Obsolete
- Function:Master Reset
- Type:JK Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:45 MHz
- Max Propagation Delay @ V, Max CL:20ns @ 5V, 15pF
- Trigger Type:Negative Edge
- Current - Output High, Low:400µA, 8mA
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Iq):6 mA
- Input Capacitance:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
