SN74S112ANSR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionJ-K FLIP-FLOP
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 10,176
Can ship immediately
Pricing:
- 1$1.24
Quote It
Technical Details
- Series:74S
- Package:Bulk
- Part Status:Obsolete
- Function:Set(Preset) and Reset
- Type:JK Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:125 MHz
- Max Propagation Delay @ V, Max CL:7ns @ 5V, 15pF
- Trigger Type:Negative Edge
- Current - Output High, Low:1mA, 20mA
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Iq):25 mA
- Input Capacitance:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:16-SO
- Package / Case:16-SOIC (0.209", 5.30mm Width)
