74LVT574MSA
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBUS DRIVER, LVT SERIES
- CategoryLogic - Flip Flops
- Datasheet 74LVT574MSA Datasheet
-
ECAD Model
- Share
In Stock: 19,247
Can ship immediately
Pricing:
- 1$1.4
Quote It
Technical Details
- Series:74LVT
- Package:Tube
- Part Status:Obsolete
- Function:Standard
- Type:D-Type
- Output Type:Tri-State, Non-Inverted
- Number of Elements:1
- Number of Bits per Element:8
- Clock Frequency:150 MHz
- Max Propagation Delay @ V, Max CL:4.6ns @ 3.3V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:32mA, 64mA
- Voltage - Supply:2.7V ~ 3.6V
- Current - Quiescent (Iq):190 µA
- Input Capacitance:4 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:20-SSOP
- Package / Case:20-SSOP (0.209", 5.30mm Width)
