SN74AS174DR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionD FLIP-FLOP, AS SERIES TTL
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 2,617
Can ship immediately
Pricing:
- 1$1.9
Quote It
Technical Details
- Series:74AS
- Package:Bulk
- Part Status:Obsolete
- Function:Master Reset
- Type:D-Type
- Output Type:Tri-State, Non-Inverted
- Number of Elements:1
- Number of Bits per Element:6
- Clock Frequency:100 MHz
- Max Propagation Delay @ V, Max CL:10ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:2mA, 20mA
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Iq):45 mA
- Input Capacitance:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:16-SOIC
- Package / Case:16-SOIC (0.154", 3.90mm Width)
