CD4027BCN
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionJ-K FLIP-FLOP
- CategoryLogic - Flip Flops
- Datasheet CD4027BCN Datasheet
-
ECAD Model
- Share
In Stock: 867
Can ship immediately
Pricing:
- 1$2.17
Quote It
Technical Details
- Series:4000B
- Package:Tube
- Part Status:Obsolete
- Function:Set(Preset) and Reset
- Type:JK Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:15.5 MHz
- Max Propagation Delay @ V, Max CL:130ns @ 15V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:8.8mA, 8.8mA
- Voltage - Supply:3V ~ 15V
- Current - Quiescent (Iq):4 µA
- Input Capacitance:5 pF
- Operating Temperature:-55°C ~ 125°C (TA)
- Mounting Type:Through Hole
- Supplier Device Package:16-PDIP
- Package / Case:16-DIP (0.300", 7.62mm)
