SN74AS576DWR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBUS DRIVER
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 1,144
Can ship immediately
Pricing:
- 1$4.59
Quote It
Technical Details
- Series:74AS
- Package:Bulk
- Part Status:Obsolete
- Function:Standard
- Type:D-Type
- Output Type:Tri-State, Inverted
- Number of Elements:1
- Number of Bits per Element:8
- Clock Frequency:125 MHz
- Max Propagation Delay @ V, Max CL:9ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:15mA, 48mA
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Iq):125 mA
- Input Capacitance:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:20-SOIC
- Package / Case:20-SOIC (0.295", 7.50mm Width)
