SN74LV574ADWR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSN74LV574A OCTAL EDGE-TRIGGERED
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 176,102
Can ship immediately
Pricing:
- 1$0.24
- 2,000$0.23635
- 6,000$0.22005
- 10,000$0.2119
Quote It
Technical Details
- Series:74LV
- Package:Bulk
- Part Status:Active
- Function:Standard
- Type:D-Type
- Output Type:Tri-State, Non-Inverted
- Number of Elements:1
- Number of Bits per Element:8
- Clock Frequency:175 MHz
- Max Propagation Delay @ V, Max CL:10.6ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:16mA, 16mA
- Voltage - Supply:2V ~ 5.5V
- Current - Quiescent (Iq):20 µA
- Input Capacitance:1.8 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:20-SOIC
- Package / Case:20-SOIC (0.295", 7.50mm Width)
