SN74HC574DW
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSN74HC574 OCTAL EDGE-TRIGGERED D
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 1,931
Can ship immediately
Pricing:
- 1$0.24
- 10$0.20478
- 25$0.19107
- 100$0.15282
- 500$0.12008
- 1,000$0.09279
- 2,500$0.0846
- 5,000$0.07914
Quote It
Technical Details
- Series:74HC
- Package:Bulk
- Part Status:Active
- Function:Standard
- Type:D-Type
- Output Type:Tri-State, Non-Inverted
- Number of Elements:1
- Number of Bits per Element:8
- Clock Frequency:36 MHz
- Max Propagation Delay @ V, Max CL:46ns @ 6V, 150pF
- Trigger Type:Positive Edge
- Current - Output High, Low:7.8mA, 7.8mA
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Iq):8 µA
- Input Capacitance:3 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:20-SOIC
- Package / Case:20-SOIC (0.295", 7.50mm Width)
