SN74LS107AD
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC FF JK TYPE DUAL 1BIT 14SOIC
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 252
Can ship immediately
Pricing:
- 1$2.32
- 10$2.08058
- 50$1.96257
- 100$1.67199
- 500$1.37374
- 1,000$1.13823
- 2,500$1.05973
- 5,000$1.02048
Quote It
Technical Details
- Series:74LS
- Package:Tube
- Part Status:Active
- Function:Reset
- Type:JK Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:45 MHz
- Max Propagation Delay @ V, Max CL:20ns @ 5V, 15pF
- Trigger Type:Negative Edge
- Current - Output High, Low:400µA, 8mA
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Iq):6 mA
- Input Capacitance:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
