SN74HC112DT
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC FF JK TYPE DUAL 1BIT 16SOIC
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 1,303
Can ship immediately
Pricing:
- 1$0.9
- 1,000$0.3855
Quote It
Technical Details
- Series:74HC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Function:Set(Preset) and Reset
- Type:JK Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:60 MHz
- Max Propagation Delay @ V, Max CL:21ns @ 6V, 50pF
- Trigger Type:Negative Edge
- Current - Output High, Low:5.2mA, 5.2mA
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Iq):4 µA
- Input Capacitance:3 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:16-SOIC
- Package / Case:16-SOIC (0.154", 3.90mm Width)
