SN74AC564PWR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSN74AC564 OCTAL D-TYPE EDGE-TRIG
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 417
Can ship immediately
Pricing:
- 1$0.92
- 2,000$0.83835
- 6,000$0.8073
- 10,000$0.77625
Quote It
Technical Details
- Series:74AC
- Package:Bulk
- Part Status:Active
- Function:Standard
- Type:D-Type
- Output Type:Tri-State, Inverted
- Number of Elements:1
- Number of Bits per Element:8
- Clock Frequency:95 MHz
- Max Propagation Delay @ V, Max CL:10.5ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:24mA, 24mA
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Iq):4 µA
- Input Capacitance:4.5 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:20-TSSOP
- Package / Case:20-TSSOP (0.173", 4.40mm Width)
