MC74LCX574DT
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBUS DRIVER
- CategoryLogic - Flip Flops
- Datasheet MC74LCX574DT Datasheet
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$0.14
Quote It
Technical Details
- Series:74LCX
- Package:Tube
- Part Status:Obsolete
- Function:Standard
- Type:D-Type
- Output Type:Tri-State, Non-Inverted
- Number of Elements:1
- Number of Bits per Element:8
- Clock Frequency:150 MHz
- Max Propagation Delay @ V, Max CL:8.5ns @ 3.3V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:24mA, 24mA
- Voltage - Supply:2V ~ 3.6V
- Current - Quiescent (Iq):10 µA
- Input Capacitance:7 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:20-TSSOP
- Package / Case:20-TSSOP (0.173", 4.40mm Width)
