SNJ54LS175J
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description54LS175 QUADRUPLE D-TYPE FLIP-FL
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$10.98
Quote It
Technical Details
- Series:54LS
- Package:Bulk
- Part Status:Active
- Function:Master Reset
- Type:D-Type
- Output Type:Complimentary
- Number of Elements:1
- Number of Bits per Element:4
- Clock Frequency:40 MHz
- Max Propagation Delay @ V, Max CL:25ns @ 5V, 15pF
- Trigger Type:Positive Edge
- Current - Output High, Low:4mA, 400µA
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Iq):18 mA
- Input Capacitance:-
- Operating Temperature:-55°C ~ 125°C (TA)
- Mounting Type:Through Hole
- Supplier Device Package:16-CDIP
- Package / Case:16-CDIP (0.300", 7.62mm)
