SN74HC574NG4

Technical Details

• Series:74HC
• Package:Tube
• Part Status:Discontinued at Digi-Key
• Function:Standard
• Type:D-Type
• Output Type:Tri-State, Non-Inverted
• Number of Elements:1
• Number of Bits per Element:8
• Clock Frequency:40 MHz
• Max Propagation Delay @ V, Max CL:31ns @ 6V, 50pF

• Trigger Type:Positive Edge
• Current - Output High, Low:7.8mA, 7.8mA
• Voltage - Supply:2V ~ 6V
• Current - Quiescent (Iq):8 µA
• Input Capacitance:3 pF
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Through Hole
• Supplier Device Package:20-PDIP
• Package / Case:20-DIP (0.300", 7.62mm)
