56AAD-B24-B15/R81L
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPANEL CONTROL - 1/2" (12.5MM)
- CategoryRotary Potentiometers, Rheostats
- Datasheet 56AAD-B24-B15/R81L Datasheet
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
- 1$9.145
- 270$7.856
Quote It
Technical Details
- Series:56
- Package:Bulk
- Part Status:Active
- Resistance (Ohms):10k
- Tolerance:±20%
- Power (Watts):0.5W, 1/2W
- Built in Switch:Rotary, SPDT
- Number of Turns:1
- Taper:Linear
- Number of Gangs:1
- Adjustment Type:Side Adjustment
- Temperature Coefficient:±1000ppm/°C
- Rotation:290°
- Resistive Material:Conductive Plastic
- Termination Style:PC Pins
- Actuator Type:Slotted
- Actuator Length:0.750" (19.05mm)
- Actuator Diameter:0.250" (6.35mm)
- Bushing Thread:3/8-32
- Mounting Type:Panel Mount
