ACPL-K49T-000E
Broadcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISOLATOR 5KV TRANSISTOR
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet ACPL-K49T-000E Datasheet
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
- 1$3.62
- 10$3.02083
- 25$2.53733
- 160$2.1748
- 320$1.93317
- 560$1.75193
- 1,040$1.60695
- 2,560$1.54049
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Channels:1
- Voltage - Isolation:5000Vrms
- Current Transfer Ratio (Min):32% @ 10mA
- Current Transfer Ratio (Max):100% @ 10mA
- Turn On / Turn Off Time (Typ):20µs, 20µs (Max)
- Rise / Fall Time (Typ):-
- Input Type:DC
- Output Type:Transistor
- Voltage - Output (Max):20V
- Current - Output / Channel:8mA
- Voltage - Forward (Vf) (Typ):1.5V
- Current - DC Forward (If) (Max):20 mA
- Vce Saturation (Max):-
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.268", 6.81mm Width)
- Supplier Device Package:8-SO
